SKU: 6941545631363
Category: Shop Online , Smart Home , Smart Entry
Availability: 5
For Installation Kindly Contact
98987295-22289170.
Charges apply accordingly
Easy Return, Quick Refund. See more.
| Model | CS-EP7 |
|---|
| Image Sensor | 1/2.7" Progressive Scan CMOS (Supports low light sensitivity) |
|---|---|
| Lens | 2.0 mm @ F2.2,viewing angle: 162° (Diagonal) |
| Day & Night | IR-cut filter with auto-switching, 850 nm infrared light × 2 (max. 6m) |
| Max. Resolution | 2K, 2048 × 1296 |
| DNR | 2D / 3D DNR |
| Video Compression | H.265 / H.264 |
| Frame Rate | Max: 15fps; Self-Adaptive during network transmission |
| Wi-Fi Standard | IEEE 802.11 AH |
|---|---|
| Frequency Range | 904 M - 928 M (US), 865 M-867 M (EU) |
| Channel Bandwidth | 8 M (U ), 2 M (EU) |
| Security | 64 / 128 bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Wi-Fi HaLow Pairing | AP pairing |
| Max Transmission Distance for Intercom and monitor | Up to 350m in open area; up to 80m in two enclosed walls |
| Open the door (Gate) | Support 2 wiring ports. 1-10m distance. The intercom panel provides a dry-contact connection, without an electric current, to connect to the button for automated gate, gate breaking capacity: 12V / 2A |
|---|---|
| Unlock (Electric strike plate) | Support 2 wiring ports. 1-10m distance. The electric strike plate or lock that you order must have a mechanical memory; the power supply to the electric strike plate or lock must not exceed 12V / 0.8A, otherwise should do as user manual. |
| Door Open Methods | 1.RFID badge unlock (CPU card × 3 pcs) 2.Password unlock 3.App remote unlock 4.Indoor display unlock |
| Multiple ringtones | Up to 20 ringtones |
|---|---|
| Functions | Live view, playback, two-way talk, video call |
| Audio Input | Built-in high-sensitivity microphone |
|---|---|
| Audio Output | Built-in high-power speaker |
| Button | Screen On / Off Button |
| Terminal | Two wiring ports to connect the power |
| Storage | Supports microSD card (Up to 512 GB) |
| Display size | 7” touch screen |
|---|---|
| Resolution | 1024 × 600 |
| In the box | - Monitor |
|---|---|
| - Wall Bracket for Monitor | |
| - Power Adapter for Monitor | |
| - Intercom Panel (Doorbell) with a Weather-proof Shield | |
| - Drill Template for Monitor | |
| - Drill Template for Intercom Panel | |
| - Screwdriver | |
| - Name Card (×3) | |
| - Badges (×3) | |
| - Screw Kit (×2) | |
| - Pin (×1) | |
| - Wires and Wire Connectors | |
| - Battery for Intercome Panel (× 1) | |
| - USB Cable for Battery (× 1) | |
| - Power Supply Jack Connector Cable (× 1) | |
| - Solar Panel (× 1) | |
| - Regulatory Information (×2) | |
| - Quick Start Guide |
| Audio Input | Built-in high-sensitivity microphone |
|---|---|
| Audio Output | Built-in high-power speaker |
| Doorbell Button | Supports 1 button. |
| Name Card | Supports handwritten. 3 cards stickers included (1 sticker already on the intercom panel). |
| Terminal | Two wiring ports to connect gate. Two wiring ports to connect electric strike plate. Two wiring ports to connect the solar panel. |
| Password Keypad | 0-9 10-digial password keyboard; support 5 sets of 6-10 digital passwords; press the keypad to turn on the light, the light can be turn off |
| Operation Conditions | -20°C to 60°C , Humidity 95% or less (non-condensing) |
|---|---|
| IP Grade | Waterproof IP65, with shield cover |
| Power Supply | Battery (7.3V), EZVIZ Doorbell Solar Panel |
| Battery Capacity | 2600 mAh 7.3V (5200mAh 3.7V) rechargeable and detachable lithium battery 85 days at the rate of using 3 minutes per day, and open the electric strike plate 10 times |
| Product Dimension | 175 × 86 × 34 mm |
| Certifications | CE / REACH / WEEE / RoHS |
|---|
