SKU: 6941545610719
Category: Security Cameras , Outdoor Wifi Cameras , Shop Online
Availability: 10
For Installation Kindly Contact
98987295-22289170.
Charges apply accordingly
Easy Return, Quick Refund. See more.
| Model | CS-H3-R100-1J5WKFL |
|---|
| Image Sensor | 1/2.7โProgressive Scan CMOS |
|---|---|
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8mm @ F2.0, viewing angle: 114ยฐ (Diagonal), 96ยฐ (Horizontal), 51ยฐ (Vertical) 4mm @ F2.0, viewing angle: 95ยฐ (Diagonal), 80ยฐ (Horizontal), 42ยฐ (Vertical) |
| Minimum Illumination | 0.01 lux @ (F2.0, AGC ON), 0 Lux with IR |
| Lens Mount | M12 |
| Day / Night Switch | IR-Cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| BLC | Supports |
| IR Night Vision Distance | Up to 98 ft / 30 m |
| Max. Resolution | 2880 ร 1620 pixels |
|---|---|
| Frame Rate | Max: 30fps; Self-Adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Quad HD+; Full HD; HD; Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 4 Mbps |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
|---|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
| Wi-Fi Pairing | AP Pairing |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Wired Network | RJ45 ร 1 (10M / 100M Adaptive Ethernet Port) |
| Detection | AI-Powered Human / Vehicle Shape Detection, Waving-Hand Detection, Motion Detection |
|---|---|
| Customized Alert Area | Supports |
| Integration | Works with Alexa, Google Assistant, IFTTT |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
| Local Storage | Supports microSD card (Up to 512 GB) |
|---|
| In the box | - EZVIZ H3 3K Camera |
|---|---|
| - Drill Template | |
| - Screw Kit | |
| - Waterproof Kit | |
| - Power Adapter | |
| - Regulatory Information | |
| - Quick Start Quide |
| Wiring | Hard-Wired |
|---|---|
| Power Supply | DC 12V / 1A |
| Power Consumption | Max. 8W |
| Dimensions | 75.5 ร 75.5 ร 155 mm (2.97 ร 2.97 ร 6.10 inch) |
|---|---|
| Package Dimensions | 227 ร 100 ร 92 mm (8.94 ร 3.94 ร 3.62 inch) |
| Weight | Net weight: 433 g (15.27 oz) With package: 652 g (23.00 oz) |
| IP Grade | IP67 |
| Operating Conditions | -30 ยฐC ~ 60 ยบC (-22 ยฐF ~ 140 ยฐF ) Humidity 95% or less (non-condensing) |
| Certifications | CE / FCC / UKCA / UL / WEEE / RoHS / REACH |
|---|
