SKU: 6941545631455
Category: Outdoor Wifi Cameras , Shop Online , Smart Home , Smart Entry
Availability: 2
For Installation Kindly Contact
98987295-22289170.
Charges apply accordingly
Easy Return, Quick Refund. See more.
| Model | CS-EP3x Pro |
|---|
| Image Sensor | 1/2.8" Progressive Scan CMOS (Supports low light sensitivity) |
|---|---|
| Lens | Upper camera: 2.3mm @F/2.2 , diagonal field of view 162° Bottom camera: 2.3mm @F/2.2 , diagonal field of view 155° |
| Day & Night | ICR infrared filter type ( Max: 6 meters) |
| Max. Resolution | Main camera: 2K (2048 × 1296) Bottom camera: 1080p (1920 × 1080) |
|---|---|
| DNR | 2D / 3D DNR |
| Video Compression | H.265 / H.264 |
| Frame Rate | 15fps.Fixed frame rate |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
|---|---|
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
|---|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64 / 128-bit WEP,WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Intelligent Alarm | AI-Powered Human Shape Detection, Package Detection |
|---|---|
| Tamper Alarm | Sound and light anti-dismantling alarm (Supports sending alerts via EZVIZ App) |
| Video Intercom | Two-Way talk |
| In the box | - EP3x Pro Video Doorbell |
|---|---|
| - Mounting Bracket for Doorbell | |
| - Inclined Mounting Bracket | |
| - Drill Template for Doorbell | |
| - Solar Panel | |
| - Drill Template for Solar Panel | |
| - Power Cable | |
| - Pin | |
| - Screw Kit ×3 | |
| - U-shaped Wire ×2 | |
| - Wire Connector ×2 | |
| - Regulatory Information ×2 | |
| - Quick Start Guide |
| Max. Power Voltage | 8.1V |
|---|---|
| Max. Power Current | 240mA |
| Max. Power | 1.2W |
| Operating Temperature | -20°C to 50°C |
| Size | 126 × 56 × 44 mm (4.96 × 2.20 × 1.73 inch) |
| IP Grade | IP65 |
| Operation Conditions | -20°C to 50°C, humidity 95% or less (non-condensing) |
|---|---|
| IP Grade | IP65 |
| Size | 166 × 50 × 31mm (6.53 × 1.97 × 1.22 inch) |
| Battery Capacity | 5200 mAh rechargeable lithium battery |
| Power Supply | 8-24VAC, type-C: 5V(±10%), EZVIZ Solar Panel |
| Power Consumption | 3W MAX |
| Certifications | CE / REACH / WEEE / RoHS |
|---|
